Roof Evaporative Air Cooler
Mounted on the roof, these evaporative air coolers mitigate the heat by moving the cooled air through ceiling and walls into your living or work spaces. With the circulation of cooled air within the rooms, the roof-mounted evaporative coolers can achieve effects of excellent cooling, air purification and natural humidification.
- Product volume: 2.10m³-9.244m³
- Weight: 113kg-827kg
- Air flow: 23000m³/h-60000m³/h
- Power: 2200W-22000W
The roof evaporative coolers are built for cooling air in many fields, such as gyms, yoga studios, libraries, hospitals, workshops, internet cafes, classrooms, conference rooms, indoor farms, supermarkets, shopping centers, restaurants, workplace canteens, warehouses, etc.
- Max. air flow: 20000m³/h
- Fan type: centrifugal
- Voltage/Frequency: 380V/50Hz
- Power: 5.5kW
- Operating current: 11.6A
- Water tank capacity: 85L
- Overall size: 1582×1442×1168mm
- Air outlet size: 550×500mm
- Net weight: 206kg
- Cooling area: 71-160m²
- Fan speed: 1
- Control mode: mechanical control (class S)
- Max. air flow: 20000m³/h
- Fan type: centrifugal
- Voltage/Frequency: 380V/50Hz
- Power: 5.5kW
- Operating current: 11.6A
- Water tank capacity: 85L
- Overall size: 1869×1729×1168mm
- Air outlet size: 550×500mm
- Net weight: 273kg
- Cooling area: 71-160m²
- Fan speed: 1
- Control mode: mechanical control (class S)
- Max. air flow: 20000m³/h
- Fan type: centrifugal
- Voltage/Frequency: 380V/50Hz
- Power: 5.5kW
- Operating current: 11.6A
- Water tank capacity: 85L
- Overall size: 1582×1442×1168mm
- Air outlet size: 550×500mm
- Net weight: 206kg
- Cooling area: 71-160m²
- Fan speed: stepless speed regulation
- Control mode: stepless speed control box
- Max. air flow: 20000m³/h
- Fan type: centrifugal
- Voltage/Frequency: 380V/50Hz
- Power: 5.5kW
- Operating current: 11.6A
- Water tank capacity: 85L
- Overall size: 1869×1729×1168mm
- Air outlet size: 550×500mm
- Net weight: 273kg
- Cooling area: 71-160m²
- Fan speed: stepless speed regulation
- Control mode: stepless speed control box
- Max. air flow: 25000m³/h
- Fan type: centrifugal
- Voltage/Frequency: 380V/50Hz
- Power: 7.5kW
- Operating current: 15.4A
- Water tank capacity: 92L
- Overall size: 1685×1545×1289mm
- Air outlet size: 620×600mm
- Net weight: 350kg
- Cooling area: 87-198m²
- Fan speed: 1
- Control mode: mechanical control (class S)
- Max. air flow: 25000m³/h
- Fan type: centrifugal
- Voltage/Frequency: 380V/50Hz
- Power: 7.5kW
- Operating current: 15.4A
- Water tank capacity: 92L
- Overall size: 1989×1849×1289mm
- Air outlet size: 620×600mm
- Net weight: 405kg
- Cooling area: 87-198m²
- Fan speed: 1
- Control mode: mechanical control (class S)
- Max. air flow: 25000m³/h
- Fan type: centrifugal
- Voltage/Frequency: 380V/50Hz
- Power: 7.5kW
- Operating current: 15.4A
- Water tank capacity: 92L
- Overall size: 1685×1545×1289mm
- Air outlet size: 620×600mm
- Net weight: 350kg
- Cooling area: 87-198m²
- Fan speed: stepless speed regulation
- Control mode: stepless speed control box
- Max. air flow: 25000m³/h
- Fan type: centrifugal
- Voltage/Frequency: 380V/50Hz
- Power: 7.5kW
- Operating current: 15.4A
- Water tank capacity: 92L
- Overall size: 1989×1849×1289mm
- Air outlet size: 620×600mm
- Net weight: 405kg
- Cooling area: 87-198m²
- Fan speed: stepless speed regulation
- Control mode: stepless speed control box
- Max. air flow: 23000m³/h
- Fan type: centrifugal
- Voltage/Frequency: 380V/50Hz
- Power: 2.2kW
- Operating current: 5.7A
- Water tank capacity: 60L
- Overall size: 1330×1330×1190mm
- Air outlet size: 545×342mm
- Noise: ≤83dB
- Net weight: 190kg
- Cooling area: 120-180m²
- Fan speed: 1
- Control mode: mechanical control (class S)
- Max. air flow: 23000m³/h
- Fan type: centrifugal
- Voltage/Frequency: 380V/50Hz
- Power: 2.2kW
- Operating current: 5.7A
- Water tank capacity: 60L
- Overall size: 1330×1330×1190mm
- Air outlet size: 545×430mm
- Noise: ≤83dB
- Net weight: 198kg
- Cooling area: 120-180m²
- Fan speed: 1
- Control mode: mechanical control (class S)
- Max. air flow: 23000m³/h
- Fan type: centrifugal
- Voltage/Frequency: 380V/50Hz
- Power: 2.2kW
- Operating current: 5.7A
- Water tank capacity: 60L
- Overall size: 1330×1330×1190mm
- Air outlet size: 545×430mm
- Noise: ≤83dB
- Net weight: 198kg
- Cooling area: 120-180m²
- Fan speed: 1
- Control mode: mechanical control (class S)
- Max. air flow: 23000m³/h
- Fan type: centrifugal
- Voltage/Frequency: 380V/50Hz
- Power: 2.2kW
- Operating current: 5.7A
- Water tank capacity: 60L
- Overall size: 1330×1330×1190mm
- Air outlet size: 545×342mm
- Noise: ≤83dB
- Net weight: 190kg
- Cooling area: 120-180m²
- Fan speed: stepless speed regulation
- Control mode: control box
- Max. air flow: 23000m³/h
- Fan type: centrifugal
- Voltage/Frequency: 380V/50Hz
- Power: 2.2kW
- Operating current: 5.7A
- Water tank capacity: 60L
- Overall size: 1330×1330×1190mm
- Air outlet size: 545×430mm
- Noise: ≤83dB
- Net weight: 198kg
- Cooling area: 120-180m²
- Fan speed: stepless speed regulation
- Control mode: control box
- Max. air flow: 23000m³/h
- Fan type: centrifugal
- Voltage/Frequency: 380V/50Hz
- Power: 2.2kW
- Operating current: 5.7A
- Water tank capacity: 60L
- Overall size: 1330×1330×1190mm
- Air outlet size: 545×430mm
- Noise: ≤83dB
- Net weight: 198kg
- Cooling area: 120-180m²
- Fan speed: stepless speed regulation
- Control mode: control box
- Max. air flow: 30000m³/h
- Fan type: axial flow
- Voltage/Frequency: 380V/50Hz
- Power: 3.2kW
- Operating current: 7.0A
- Water tank capacity: 60L
- Overall size: 1330×1330×1190mm
- Air outlet size: 900×900mm
- Noise: ≤83dB
- Net weight: 113kg
- Cooling area: 120-200m²
- Fan speed: 1
- Control mode: mechanical control (class A)
- Max. air flow: 30000m³/h
- Fan type: axial flow
- Voltage/Frequency: 380V/50Hz
- Power: 3.2kW
- Operating current: 7.0A
- Water tank capacity: 60L
- Overall size: 1330×1330×1190mm
- Air outlet size: 900×900mm
- Noise: ≤83dB
- Net weight: 121kg
- Cooling area: 120-200m²
- Fan speed: 1
- Control mode: mechanical control (class A)
- Max. air flow: 30000m³/h
- Fan type: axial flow
- Voltage/Frequency: 380V/50Hz
- Power: 3.2kW
- Operating current: 7.0A
- Water tank capacity: 60L
- Overall size: 1330×1330×1190mm
- Air outlet size: 900×900mm
- Noise: ≤83dB
- Net weight: 113kg
- Cooling area: 120-200m²
- Fan speed: 1
- Control mode: mechanical control (class S)
- Max. air flow: 30000m³/h
- Fan type: axial flow
- Voltage/Frequency: 380V/50Hz
- Power: 3.2kW
- Operating current: 7.0A
- Water tank capacity: 60L
- Overall size: 1330×1330×1190mm
- Air outlet size: 900×900mm
- Noise: ≤83dB
- Net weight: 121kg
- Cooling area: 120-200m²
- Fan speed: 1
- Control mode: mechanical control (class S)
- Max. air flow: 30000m³/h
- Fan type: axial flow
- Voltage/Frequency: 380V/50Hz
- Power: 3.2kW
- Operating current: 7.0A
- Water tank capacity: 60L
- Overall size: 1330×1330×1190mm
- Air outlet size: 900×900mm
- Noise: ≤83dB
- Net weight: 113kg
- Cooling area: 120-200m²
- Fan speed: 1
- Control mode: LCD control panel (single speed)
- Max. air flow: 30000m³/h
- Fan type: axial flow
- Voltage/Frequency: 380V/50Hz
- Power: 3.2kW
- Operating current: 7.0A
- Water tank capacity: 60L
- Overall size: 1330×1330×1190mm
- Air outlet size: 900×900mm
- Noise: ≤83dB
- Net weight: 121kg
- Cooling area: 120-200m²
- Fan speed: 1
- Control mode: LCD control panel (single speed)
- Max. air flow: 30000m³/h
- Fan type: axial flow
- Voltage/Frequency: 380V/50Hz
- Power: 3.2kW
- Operating current: 7.0A
- Water tank capacity: 60L
- Overall size: 1330×1330×1190mm
- Air outlet size: 900×900mm
- Noise: ≤83dB
- Net weight: 113kg
- Cooling area: 120-200m²
- Fan speed: stepless speed regulation
- Control mode: control box
- Max. air flow: 30000m³/h
- Fan type: axial flow
- Voltage/Frequency: 380V/50Hz
- Power: 3.2kW
- Operating current: 7.0A
- Water tank capacity: 60L
- Overall size: 1330×1330×1190mm
- Air outlet size: 900×900mm
- Noise: ≤83dB
- Net weight: 121kg
- Cooling area: 120-200m²
- Fan speed: stepless speed regulation
- Control mode: control box
- Max. air flow: 30000m³/h
- Fan type: centrifugal
- Voltage/Frequency: 380V/50Hz
- Power: 11kW
- Operating current: 22A
- Water tank capacity: 103L
- Overall size: 1838×1698×1324mm
- Air outlet size: 700×650mm
- Net weight: 410kg
- Cooling area: 113-263m²
- Fan speed: 1
- Control mode: single speed control box
- Max. air flow: 30000m³/h
- Fan type: centrifugal
- Voltage/Frequency: 380V/50Hz
- Power: 11kW
- Operating current: 22A
- Water tank capacity: 103L
- Overall size: 2090×1950×1292mm
- Air outlet size: 700×650mm
- Net weight: 460kg
- Cooling area: 113-263m²
- Fan speed: 1
- Control mode: single speed control box
- Max. air flow: 30000m³/h
- Fan type: centrifugal
- Voltage/Frequency: 380V/50Hz
- Power: 11kW
- Operating current: 22A
- Water tank capacity: 103L
- Overall size: 1838×1698×1324mm
- Air outlet size: 700×650mm
- Net weight: 410kg
- Cooling area: 113-263m²
- Fan speed: stepless speed regulation
- Control mode: stepless speed control box
- Max. air flow: 30000m³/h
- Fan type: centrifugal
- Voltage/Frequency: 380V/50Hz
- Power: 11kW
- Operating current: 22A
- Water tank capacity: 103L
- Overall size: 2090×1950×1292mm
- Air outlet size: 700×650mm
- Net weight: 460kg
- Cooling area: 113-263m²
- Fan speed: stepless speed regulation
- Control mode: stepless speed control box
- Max. air flow: 35000m³/h
- Fan type: centrifugal
- Voltage/Frequency: 380V/50Hz
- Power: 15kW
- Operating current: 29A
- Water tank capacity: 106L
- Overall size: 1888×1748×1414mm
- Air outlet size: 780×750mm
- Net weight: 510kg
- Cooling area: 179-332m²
- Fan speed: 1
- Control mode: single speed control box
- Max. air flow: 35000m³/h
- Fan type: centrifugal
- Voltage/Frequency: 380V/50Hz
- Power: 15kW
- Operating current: 29A
- Water tank capacity: 106L
- Overall size: 2186×2046×1414mm
- Air outlet size: 780×750mm
- Net weight: 550kg
- Cooling area: 179-332m²
- Fan speed: 1
- Control mode: single speed control box
- Max. air flow: 35000m³/h
- Fan type: centrifugal
- Voltage/Frequency: 380V/50Hz
- Power: 15kW
- Operating current: 29A
- Water tank capacity: 106L
- Overall size: 1888×1748×1414mm
- Air outlet size: 780×750mm
- Net weight: 510kg
- Cooling area: 179-332m²
- Fan speed: stepless speed regulation
- Control mode: stepless speed control box
- Max. air flow: 35000m³/h
- Fan type: centrifugal
- Voltage/Frequency: 380V/50Hz
- Power: 15kW
- Operating current: 29A
- Water tank capacity: 106L
- Overall size: 2186×2046×1414mm
- Air outlet size: 780×750mm
- Net weight: 550kg
- Cooling area: 179-332m²
- Fan speed: stepless speed regulation
- Control mode: stepless speed control box
- Max. air flow: 45000m³/h
- Fan type: centrifugal
- Voltage/Frequency: 380V/50Hz
- Power: 18.5kW
- Operating current: 36A
- Water tank capacity: 119L
- Overall size: 2087×1947×1538mm
- Air outlet size: 860×800mm
- Net weight: 550kg
- Cooling area: 200-367m²
- Fan speed: 1
- Control mode: single speed control box
- Max. air flow: 45000m³/h
- Fan type: centrifugal
- Voltage/Frequency: 380V/50Hz
- Power: 18.5kW
- Operating current: 36A
- Water tank capacity: 119L
- Overall size: 2357×2217×1414mm
- Air outlet size: 860×800mm
- Net weight: 603kg
- Cooling area: 200-367m²
- Fan speed: 1
- Control mode: single speed control box
- Max. air flow: 45000m³/h
- Fan type: centrifugal
- Voltage/Frequency: 380V/50Hz
- Power: 18.5kW
- Operating current: 36A
- Water tank capacity: 119L
- Overall size: 2087×1947×1538mm
- Air outlet size: 860×800mm
- Net weight: 550kg
- Cooling area: 200-367m²
- Fan speed: stepless speed regulation
- Control mode: stepless speed control box
- Max. air flow: 45000m³/h
- Fan type: centrifugal
- Voltage/Frequency: 380V/50Hz
- Power: 18.5kW
- Operating current: 36A
- Water tank capacity: 119L
- Overall size: 2357×2217×1414mm
- Air outlet size: 860×800mm
- Net weight: 603kg
- Cooling area: 200-367m²
- Fan speed: stepless speed regulation
- Control mode: stepless speed control box
- Max. air flow: 60000m³/h
- Fan type: centrifugal
- Voltage/Frequency: 380V/50Hz
- Power: 22kW
- Operating current: 43.2A
- Water tank capacity: 126L
- Overall size: 2186×2046×1656mm
- Air outlet size: 920×855mm
- Net weight: 816kg
- Cooling area: 227-460m²
- Fan speed: 1
- Control mode: single speed control box
- Max. air flow: 60000m³/h
- Fan type: centrifugal
- Voltage/Frequency: 380V/50Hz
- Power: 22kW
- Operating current: 43.2A
- Water tank capacity: 126L
- Overall size: 2433×2293×1657mm
- Air outlet size: 920×855mm
- Net weight: 827kg
- Cooling area: 227-460m²
- Fan speed: 1
- Control mode: single speed control box
- Max. air flow: 60000m³/h
- Fan type: centrifugal
- Voltage/Frequency: 380V/50Hz
- Power: 22kW
- Operating current: 43.2A
- Water tank capacity: 126L
- Overall size: 2186×2046×1656mm
- Air outlet size: 920×855mm
- Net weight: 816kg
- Cooling area: 227-460m²
- Fan speed: stepless speed regulation
- Control mode: stepless speed control box
- Max. air flow: 60000m³/h
- Fan type: centrifugal
- Voltage/Frequency: 380V/50Hz
- Power: 22kW
- Operating current: 43.2A
- Water tank capacity: 126L
- Overall size: 2433×2293×1657mm
- Air outlet size: 920×855mm
- Net weight: 827kg
- Cooling area: 227-460m²
- Fan speed: stepless speed regulation
- Control mode: stepless speed control box
